Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset

Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset
Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset

Large Image :  Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset

Product Details:
Place of Origin: Guangdong, China
Brand Name: dell
Model Number: r940xa
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: $4,230.00/pieces >=1 pieces
Contact Now

Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset

Description
Private Mold: Yes Products Status: Stock
Type: Rack Processor Type: Intel, Support Intel Xeon
Product Name: R940XA Memory Type: 24 * DDR4 RDIMM
Hard Drive Type: 8 * 3.5inch SAS/SATA Power Supply Type: 495/750/1100/1600/2000 W
RAID Card: H330/H730/H740P Warranty: 3 Years
Network Port: Double Port Gigabit CS(chipset): C621
System: Windows Server/Linux

Product Description
Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset 0
Dell PowerEdge R940xa Rack Server
Dramatically accelerating artificial intelligence and machine learning
Quickly turn data insights into business results with PowerEdge R940xa. The R940xa delivers powerful four-way performance in an
expandable 4U design for application acceleration.

A powerful 1:1 combination of four cpus and four Gpus drives database acceleration
Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset 1
Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset 2
Maximize application performance and density
PowerEdge R940xa enables GPU database acceleration to provide real-time decision making for computationally intensive applications. The R940xa uses a combination of four cpus and four Gpus to deliver consistent high performance for demanding applications. R940xa allows you to dynamically scale capacity and performance as your business-critical workloads change, including: • Maximize performance with Intel ® Xeon ® expandable processors, up to 112 cores. • Choose from up to four double-width Gpus or up to eight FPgas to speed up applications. • Supports large data sets of up to 48 DIMMs (12 of which can be NVDIMM) and up to 6TB memory. • Expand local capacity with up to 32 2.5-inch HDDS/SSDS and up to four direct-connected NVMe drives. • Connect external devices with up to 12 PCIe slots for fast expansion.
Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset 3

Automate maintenance through Dell EMC OpenManage

The Dell EMC OpenManage™ portfolio helps streamline overall data center IT operations by enabling intelligent, automated management of daily tasks. The R940xa is combined with unique agent-free administration capabilities for easy administration, freeing you up to perform advanced projects. • Leverage your existing IT management platform with rich OpenManage integration and connectivity. • Take advantage of QuickSync 2 and easily access your server from your phone or tablet.
Dell PowerEdge R940XA 4U Rack Server Barebone with 8 x 3.5" Backplane and C621 Chipset 4

Protect your data center with built-in security

Each PowerEdge server has a network resilience architecture that integrates security into the full server life cycle. R940xa has the new security features described above, so you can safely and reliably deliver the right data to your customers wherever they are. Dell EMC considers every aspect of system security, from design to termination of service, to ensure that trust is built and a secure and worry-free system is provided. Rely on a supply chain of security components to ensure security from the factory to the data center. • Secure data with encrypted signed firmware packages and secure startup. • Prevent unauthorized or malicious changes with server locking. • System erase quickly and securely erases all data from storage media, including hard drives, solid-state drives, and system memory.
Specification
Technical specification
Dell PowerEdge R940xa Rack Server
processor
Up to four Intel ® Xeon ® scalable processors with up to 28 cores per processor
memory

48 DDR4 DIMM slots support RDIMMs or LRDIMMs, with speeds up to 2666MT/s and up to 6TB
Up to 12 NVMS with up to 384GB
Only Registered ECC DDR4 DIMMs are supported
Memory controller
Internal controller: PERC H730P, H740P, H330 software RAID (SWRAID) S140 Start the optimized storage subsystem:
HWRAID, 2 M.2 SSDS, 120 GB or 240 GB External PERC (RAID) : H840 12Gbps SAS HBA (non-RAID) : External 12Gbps SAS HBA (non-RAID).
Internal HBA330 (Non-RAID)
Driver bracket
Front-end driver bracket: Up to 8 2.5-inch SAS/SATA (HDD/SSD), up to 30TB, or up to 24 2.5-inch SAS/SATA (HDD/SSD),
up to 92TB, Or up to 32 SAS/SATA (HDD/SSD) with up to 4 NVME PCIe SSDS for up to 132TB
Power supply

Platinum: 1100W, 1600W, 2000W, 2400W
DC: 1100W
Mixed mode /HVDC: 1100W1
Hot swap power supply with full redundancy option
Six hot-swappable fans with N +1 redundancy
dimension

Dimensions: Frame (4U)
Chassis length: 482 mm
Chassis weight: 56 kg
Chassis depth: 812 mm
baffle
Optional LCD baffle or safety baffle
tool

Dell EMC Repository Manager
Dell EMC updated software package
Dell EMC System Update
Dell EMC Server Update Utility
security

TPM 1.2/2.0 (Optional)
Firmware signed in encrypted mode
Silicon trust root
Safe start
System locking
Safe erase
I/O and ports

Network subcard options
Four 1GE, four 10GE, two 10GE+ two 1GE, or two 25GE
Front-end ports: Video, 2 USB 2.0, 1 managed (micro-sub) dedicated IDRAC for direct USB connection.
Back-end port: Video, serial port, 2 USB 3.0
Internal port: 1 USB 3.0
Video card: VGA
PCIe: Up to 12 Gen3 slots, (6x16 slots or 2x16 + 10x8 slots)
Accelerator options:

Up to 4 double-width Gpus or up to 8 full-height FPGas
GPU: Nvidia Tesla P100, P40, V100
Supported operating systems

Canonical® Ubuntu® LTS
Citrix® XenServer®
Microsoft Windows Server® using Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi
For more information on specifications and interoperability, see
Dell.com/OSsupport
