Product Details:
|
| Products Status: | Stock | Product Name: | Thinkstation P7 |
|---|---|---|---|
| Processors: | Intel Xeon W5-3423 | Processor Parameter: | 4.2GHz, 12C/24T |
| Memory: | 16GB DDR5 4800MHz | Memory Slots: | Up To 1TB DDR5 4800MHz* (128 GB X 8) |
| HDD: | 256G SSD+2T SATA | Storage: | Up To 6 Total Drives |
| Graphic Card: | NVIDIA T400 4GB GDDR6 | Power Supply: | 1000W |
| Dimensions (H X W X D): | 440mm X 165mm X 460mm | Port: | All Port |
item | Thinkstation P7 |
Processor | * Intel® Xeon® W5-3423 Processor (2.10 GHz, up to 4.20 GHz with Turbo Boost, 12 Cores, 24 Threads, 30 MB Cache) * Intel® Xeon® W5-3425 Processor (3.20 GHz, up to 4.60 GHz with Turbo Boost, 12 Cores, 24 Threads, 30 MB Cache) * Intel® Xeon® W5-3433 Processor (2.00 GHz, up to 4.20 GHz with Turbo Boost, 16 Cores, 32 Threads, 45 MB Cache) * Intel® Xeon® W7-3445 Processor (2.60 GHz, up to 4.80 GHz with Turbo Boost, 20 Cores, 40 Threads, 52.5 MB Cache) * Intel® Xeon® W5-3435X Processor (3.10 GHz, up to 4.70 GHz with Turbo Boost, 16 Cores, 32 Threads, 45 MB Cache) * Intel® Xeon® W7-3455 Processor (2.50 GHz, up to 4.80 GHz with Turbo Boost, 24 Cores, 48 Threads, 67.5 MB Cache) * Intel® Xeon® W7-3465X Processor (2.50 GHz, up to 4.80 GHz with Turbo Boost, 28 Cores, 56 Threads, 75 MB Cache) * Intel® Xeon® W9-3475X Processor (2.20 GHz, up to 4.80 GHz with Turbo Boost, 36 Cores, 72 Threads, 82.5 MB Cache) * Intel® Xeon® W9-3495X Processor (1.90 GHz, up to 4.80 GHz with Turbo Boost, 56 Cores, 112 Threads, 105 MB Cache) |
Operating System | Windows 11 Pro for Workstations |
Graphics | * NVIDIA® T400 4GB GDDR6 * NVIDIA® T1000 8GB GDDR6 * NVIDIA® RTX™ A2000 12GB GDDR6 * NVIDIA® RTX™ A4000 16GB GDDR6 * NVIDIA® RTX™ A5500 24GB GDDR6 * NVIDIA® RTX™ A4500 20GB GDDR6 |
Memory | Up to 1TB DDR5 4800MHz* (128 GB x 8) 4800MHz max speed; available depending on configuration; 1TB available summer 2023 |
Storage | * Up to 4 TB x 3 PCIe SSD Gen 4 * Up to 2 TB PCIe SSD Gen 4 * Up to 12 TB x 3 7200RPM HDD |
RAID | * M.2 = 0 / 1 / 10 / 5* * SATA = 0 / 1 / 10 / 5* |
Audio | Audio |
Ports/Slots | Front: * Headphone / mic combo * 2 x USB-A 3.2 Gen 2 (10Gbps, 1 x always on) * 2 x USB-C 3.2 Gen 2 (10Gbps) Rear: * 2 x USB 2.0 * 3 x USB-A 3.2 Gen 2 (10Gbps) * USB-C 3.2 Gen 2x2 (20Gbps) * 2 x Ethernet (RJ45): 1 x 1Gbps, 1 x 10Gbps * Line in * Line out Optional Rear: * Serial |
Network | Onboard Ethernet:(Select Models) * Intel® Ethernet I219-LM * Marvell AQtion AQC-113C * Supports wake-on LAN Optional Ethernet: * Intel® I210-T1 Single Port Gigabit Ethernet Adapter * Intel® I350-T2 Dual Port Gigabit Ethernet Adapter * Intel® I350-T4 Quad Port Gigabit Ethernet Adapter Optional WLAN: * Intel® WiFi 6E AX210 (2x2ax)* with vPro® + Bluetooth® 5.1 |
Dimensions (H x W x D) | 440mm x 175mm x 508mm / 17.1″ x 6.9″ x 20.0″ |
Weight | Up to 24.5kg / 50lbs |
Material | System * 65% post-consumer content (PCC) recycled plastic in front and rear bezel * 35% PCC recycled plastic inside the chassis Packaging * Carton: 90% recycled and/or FSC certified content* * Cushion: 90% recycled EPE |
Power supply | * 1000W (92% efficient) * 1400W (92% efficient) * Front and Rear power button available |
